The structure of the Transmissive Photoelectric Sensor is that the light-emitting elements and the light-receiving elements are arranged in opposite directions. When an object passes between them, the light is blocked to detect the object.
Dust-proof structure
1-point screw assembly type
Printer/copier/OA machine Vending machine/ticket vending machine Detect various locations
| Maximum Glass Tube Length | with plugtransmissive |
|---|---|
| Lead Diameter | Tr |
| Contact Form | - |
| Maximum Rated Power | 1-point screw mounting type, dust-proof structure |
| Maximum Operating Voltage | 5 |
| Maximum Operating Current | 0.5 |
