The structure of the Transmissive Photoelectric Sensor is that the light-emitting elements and the light-receiving elements are arranged in opposite directions. When an object passes between them, the light is blocked to detect the object.
Buckle assembly type
Corresponds to 3 installation plate thicknesses (1.0mm, 1.2mm, 1.6mm)
Slot width: 5mm, gap width: 05mm
Printer/copier/OA machine Vending machine/ticket vending machine Detect various locations
| Maximum Glass Tube Length | with plugTransmissive |
|---|---|
| Lead Diameter | Tr |
| Contact Form | - |
| Maximum Rated Power | Snap-on mounting type, there are three types of mounting plate thickness available (1.0mm, 1.2mm, 1.6mm) |
| Maximum Operating Voltage | 5 |
| Maximum Operating Current | 0.5 |
