| Item |
Value |
| Characteristics |
Lamp load use |
| Contact Material |
Rhodium |
| Standard Coil |
N-103 |
| Ampere-turns |
30 ~ 50 AT |
| Drop-out Amps (min) |
10 A |
| Operating Time (max) |
1.0 ms |
| Release Time (max) |
0.05 ms |
| Bounce Time |
0.5 ms |
| Max. Switching Power |
10 W |
| Max. Switching Voltage |
100 VDC |
| Max. Switching Current |
3 A |
| Max. Carrying Current |
2.0 A |
| Contact Resistance |
150 mΩ |
| Withstand Voltage |
250 VDC |
| Insulation Resistance |
109 Ω (100 VDC) |
| Shock and Vibration Resistance |
Faulty operation: 98 m/s2
Fracture: 490 m/s2 |
| Operating Temperature |
-40° ~ 125° C |
| Reed Resonant Frequency |
4.3 kHz |
| Mechanical Life (operations) |
108 |
| Electrical Life (resistive loads) |
5 X 107 (5 VDC,
10mA) |
|
 |
